Composition
Polyester non-woven fabric, super absorbent resin, polyester bulky fabric, semi-conductive adhesive
Application
Apply where a robust tape is required and be used for water blocking, shielding and buffering in neutral screen wire between cable components in high voltage power cable.
Property | Unit | Type | Test Method | |
|---|---|---|---|---|
| YCWB-150 | YCWB-200 | |||
Thickness | mm | 1.5±0.6 | 2.0±0.6 | ISO9073-2 |
| Mass per unit area | g/m² | 230±40 | 260±40 | ISO9073-1 |
| Tensile strength | N/cm | ≥40 | ≥40 | ISO9073-3 |
| Elongation | % | ≥12 | ≥12 | ISO9073-3 |
| Surface resistance | Ohm/ | ≤1500 | ≤1500 | DIN53482 |
| Volume resistance | Ohm.cm | ≤10⁶ | ≤10⁶ | DIN54345 |
| Swelling speed | mm/1’00 | ≥8 | ≥10 | YS Method |
| Swelling height | mm/3’00 | ≥12 | ≥15 | YS Method |
| Short-term stability | ℃ | 230 | 230 | YS Method |
| Long-term stability | ℃ | 90 | 90 | IEC216 |
| Moisture content | % | ≤9 | ≤9 | ISO287 |
