Composition
Polyester woven fabric
Semi-conductive bonder
Application
Separating, binding /Between Power cable components
Property | Unit | YSCN-10 | YSCN-12 | YSCN-14 | Test method |
---|---|---|---|---|---|
Thickness | mm | 0.10±0.02 | 0.12±0.02 | 0.14±0.02 | ISO9073-2 |
Mass per unit area | g/m² | 80±10 | 90±10 | 100±10 | ISO9073-1 |
Tensile strength | N/cm | ≥120 | ≥140 | ≥160 | ISO9073-3 |
Elongation | % | ≥25 | ≥25 | ≥25 | ISO9073-3 |
Short term stability | ℃ | 230 | 230 | 230 | YS Method |
Long term stability | ℃ | 145 | 145 | 145 | IEC 216 |
Surface Resistance | Ω | ≤1000 | ≤1000 | ≤1000 | DIN53482 |
Volume Resistance | Ω·m | <1×10⁶ | <1×10⁶ | <1×10⁶ | DIN54345 |
Moisture content | % | ≤9 | ≤9 | ≤9 | ISO287 |
