Composition

Polyester non-woven fabric, super absorbent resin, semi-conductive adhesive

Application

Apply where a robust tape is required and be used for water blocking in neutral screen wire between cable components. It has the excellent tensile strength.

INQUIRY NOW

Technical Data

Property	Unit	Type		Test Method
Property	Unit	YCBH-40	YCBH-50	Test Method
Thickness	mm	0.40±0.05	0.50±0.05	ISO9073-2
Mass per unit area	g/m²	130±20	150±20	ISO9073-1
Tensile strength	N/cm	≥80	≥100	ISO9073-3
Elongation	%	≥12	≥12	ISO9073-3
Surface resistance	Ohm/	≤1500	≤1500	DIN53482
Volume resistance	Ohm.cm	≤10⁶	≤10⁶	DIN54345
Swelling speed	mm/1’00	≥8	≥10	YS Method
Swelling height	mm/3’00	≥12	≥15	YS Method
Short-term stability	℃	230	230	YS Method
Long-term stability	℃	90	90	IEC216
Moisture content	%	≤9	≤9	ISO287
