Composition
Polyester woven fabric
Semi-conductive bonder
Application
Separating, binding /Between Power cable components
Property | Unit | YCNH-15 | YCNH-18 | YCNH-20 | Test method |
---|---|---|---|---|---|
Thickness | mm | 0.15±0.02 | 0.18±0.02 | 0.20±0.02 | ISO9073-2 |
Mass per unit area | g/m² | 110±10 | 150±10 | 170±10 | ISO9073-1 |
Tensile strength | N/cm | ≥150 | ≥200 | ≥250 | ISO9073-3 |
Elongation | % | ≥20 | ≥20 | ≥20 | ISO9073-3 |
Short term stability | ℃ | 230 | 230 | 230 | YS Method |
Long term stability | ℃ | 145 | 145 | 145 | IEC 216 |
Surface Resistance | Ω | ≤1000 | ≤1000 | ≤1000 | DIN53482 |
Volume Resistance | Ω·m | <1×10⁶ | <1×10⁶ | <1×10⁶ | DIN54345 |
Moisture content | % | ≤6 | ≤6 | ≤6 | ISO287 |
